To view sensor status:
1. In the side navigation bar, click a target device name.
2. Click the Sensor tab.
3. In the top navigation bar, click Sensor. The Sensor window and a detailed list of sensors and
corresponding information appears.

Viewing SEL events

You may use the MergePoint SP manager to view the SEL (System Event Log) on a managed
target device.
To view SEL events:
1. In the side navigation bar, click a target device name.
2. Click the SEL tab.
3. In the top navigation bar, click SEL. The SEL window and a detailed SEL event list appears.
To clear the SEL events:
1. In the side navigation bar, click a target device name.
2. Click the SEL tab.
3. In the top navigation bar, click SEL. The SEL window appears.
4. Click Clear All SEL. All currently listed events are removed from the list.

Viewing the accounting log

The accounting log records and displays all MergePoint SP manager operations. The WEB
accounting log displays operations performed using the MergePoint SP manager web interface.
Mgpshell accounting log displays operations performed using Mgpshell. Detailed information
including operation time, login username, operation type, target device and console IP are
displayed in the accounting log.
To view the accounting log (Admin users only):
1. Click the Accounting Log tab.
2. Click WEB to view operations performed through the MergePoint SP manager web interface.
-or-
Click Mgpshell to view operations performed through the Mgpshell.

Import/export data

This function allows you to backup and restore the MergePoint SP manager by exporting the data
to the client PC or a storage location on the network.
