4. Click Connect.
SSH console
You can also access the SSH console of the selected target device. After accessing the SSH
console, you can launch the management application from the service processor's command line.
To access the SSH console:
1. In the side navigation bar, click a target device name.
2. Click the Console tab.
3. In the top navigation bar, click SSH Console.The SSH Console window opens.
4. Click Connect.

Configuring SoL parameters

The MergePoint SP manager allows you to define SoL parameters for target devices, including
Enable/Disable Serial over LAN, baud rate and channel privilege limit level.
To configure SoL parameters:
1. In the side navigation bar, click a target device name.
2. Click the Configuration tab.
3. In the top navigation bar, click Serial over LAN. The Serial over LAN Configuration
window appears.
4. Specify any of the following information:
a. Select or deselect Enable Serial over LAN as desired.
b. From the Baud Rate drop-down menu, select the baud rate.
c. From the Channel Privilege Level Limit drop-down menu, select Administrator, Operator
or User as the privilege level.
d. From the Retry Count drop-down menu, select the number of times for a retry to occur,
from 0 to 7 times.
e. In the Retry Interval field, enter the number of 10 milliseconds to elapse between
each retry.
5. Click Apply.

NFS

Network File System (NFS) provides remote access to SoL history information across networks.
By default, SoL history information is saved to the MergePoint SP manager. To free memory space
on the MergePoint SP manager, you may configure the SoL history data to be saved to another
network location and access the SoL directories from anywhere on the network.
To configure NFS storage of SoL history data (Admin users only):
1. Click System - NFS.
Chapter 3: Operations 61
