MergePoint SP5300 Appliance Configuration

1

Figure 1.1: MergePoint SP5300 Appliance Configuration

Table 1.1: Descriptions for MergePoint SP5300 Appliance Configuration

Number Description
1 Remote User Web Interface
2 LAN
3 Target Device
4 CAT 5 Cables
5 MergePoint SP5300 Appliance

LEDs on the MergePoint SP5300 appliance

On the front of the MergePoint SP5300 appliance, the LAN LED provides information about the
LAN activity; the LED blinks to indicate activity. The power LED is green if the MergePoint
SP5300 appliance is turned on.
2
4
6
7
8
3
5
9
Number
6 RJ-45 Ethernet Ports
7 Power
8 Connection to the Serial Port
9 Terminal or Workstation (for Configuration)
Chapter 1: Product Overview 3
