Avocent MERGEPOINT 53XX SP MANAGER Installer/User Manual page 137

Table 7.3: Setting Top Level CLI Parameters (Continued)
Parameter Command
syslog destination Use the set syslog destination command parameters to configure a syslog destination
(either the MergePoint SP manager console or rootuser or a syslog server name that has
been added using the add syslog destination <syslog_server_name> command).
Synopsis: set syslog [destination<dest> enable <yes|no> type <type> usertty
<username> tcp <ip> udp <ip> file <file name> pipe <name> template <num>
Example: set syslog destination dest1 enable yes type tcp tcp 127.2.2.2
NOTE: See the add command for the following second level syslog parameter: destination
on page 109.
syslog filter Use the set syslog filter command to enable a syslog filter level.
Synopsis: set syslog filter sysfilter|webfilter level
<emerg|alert|crit|err|warn|notice|info|debug <yes | no>
Example: set syslog filter sysfilter level emerg no alert no err yes notice yes
syslog presets Use the set syslog presets command to set yes or no for enabling syslog to the root user
or console.
Synopsis: set syslog presets rootuser|console <yes|no>
Example: set syslog presets rootuser yes console yes
timezone Use the set timezone command to specify the timezone using a file relative to /etc/
timezone.conf, for example GMT+8.
Synopsis: set timezone <timezone>
Example: set timezone GMT+5
tcpdump source- Use the set tcpdump command to define the IP packge filter parameters for the debug.
ip|source- Synopsis: set tcpdump source-ip <source_iP> source-port <source_port> destination-ip
port|destination- <destination_ip> destination-port <destination_IP> protocol <all|ip|tcp|udp|icmp|igmp>
ip|destination- interface <interface>
port|protocol|interf Example: set tcpdump source-ip 1.1.1.1 source-port 1500 destination-ip 1.1.1.49
ace destination-port 1500 protocol ip interface eth0
NOTE: For the MergePoint SP5300 appliance, the interface is all, eth0 or eth1.
For the MergePoint SP5324/SP5340 appliance, the interface is all, eth0, eth1, priv0,
bond0 or br0.
tcpdump state Use the set tcpdump command to start or stop the debug.
Synopsis: set tcpdump state on|off
Example: set tcpdump state on
NOTE: Setting the state to on or off will start or stop the tracing process.
Chapter 7: Using the CLI Utility 123
