Spanning-Tree Mst Port-Priority - Dell PowerConnect 5324 Command Line Interface Reference Manual

Command Mode
Global Configuration mode
User Guidelines
• There are no user guidelines for this command.
Example
The following example configures the maximum number of hops that a packet travels in an MST
region before it is discarded to 10.
Console (config) # spanning-tree mst max-hops 10

spanning-tree mst port-priority

The spanning-tree mst port-priority Interface Configuration mode command configures port
priority for the specified MST instance. To return to the default configuration, use the no form of
this command.
Syntax
spanning-tree mst instance-id port-priority priority
no spanning-tree mst instance-id port-priority
• instance-ID — ID of the spanning tree instance. (Range: 1-15)
• priority — The port priority. (Range: 0 - 240 in multiples of 16)
Default Setting
The default port priority for IEEE Multiple Spanning Tree Protocol (MSTP) is 128.
Command Modes
Interface Configuration (Ethernet, port-channel) mode
User Guidlines
• There are no user guidelines for this command.
Example
The following example configures the port priority of port g1 to 142.
Console(config)# interface ethernet g1
Console(config-if)# spanning-tree mst 1 port-priority 142
270
Spanning-Tree Commands
