CHAPTER 15

Providing Power to the TX Matrix Router

Overview of Providing Power to the TX Matrix Router

Copyright © 2010, Juniper Networks, Inc.
Overview of Providing Power to the TX Matrix Router on page 125
Tools and Parts Required for Connecting the TX Matrix Router to Power on page 126
Connecting Power to a Two-Input 160-A Power Supply in a TX Matrix Router on page 126
Connecting Power to a Three-Input 240-A Power Supply In 2-INPUT Mode in a TX
Matrix Router on page 128
Powering On the TX Matrix Router on page 130
Powering Off the TX Matrix Router on page 131
To provide power to the TX Matrix Plus router:
Read the safety guidelines and warnings for working with electricity.
1.
See "TX Matrix General Electrical Safety Guidelines" on page 319, "TX Matrix DC Power
Electrical Safety Guidelines" on page 323, "DC Power Electrical Safety Warnings for M
Series, MX Series, and T Series Routers" on page 324, and "General Electrical Safety
Warnings for M Series, MX Series, and T Series Routers" on page 319.
2. Gather the tools for connecting to power.
2.
See "Tools and Parts Required for Connecting the TX Matrix Router to Power" on
page 126.
4. Connect the DC power cables to the power supplies.
3.
See "Connecting Power to a Two-Input 160-A Power Supply in a TX Matrix Router"
on page 126 or "Connecting Power to a Three-Input 240-A Power Supply In 2-INPUT
Mode in a TX Matrix Router" on page 128.
NOTE: Redundant power supplies must be the same hardware model
number. You cannot mix a two-input 160-A power supply and three-input
240-A power supply In the same router, except when upgrading the power
supplies.
Power on the TX Matrix router.
4.
125
