NOTE: The RJ-45 port labeled
The cable connections provided in Table 3 on page 11 apply to routing matrix
configurations using from one through four T640 routers. For example, if you have a
single T640 router in your configuration, the connections from each TX-CIP to chassis
are presented in the first row of the table. If you have two T640 routers in your
LCC0
configuration, the connections from each TX-CIP to chassis
in the first two rows of the table, and so on.
NOTE: The RJ-45 ports labeled
for future use.

Table 3: Cable Connections between TX-CIPs and T-CBs

TX-CIP-0 Port and Destination
LCC0 — T-CB-0 in LCC0
LCC1 — T-CB-0 in LCC1
LCC2 — T-CB-0 in LCC2
LCC3 — T-CB-0 in LCC3
Figure 5 on page 12 shows the control and switching planes connections between the
TX Matrix router and a T640 router. The control plane connections are in the center.
Chapter 2: TX Matrix System Architecture Overview
on a T-CB is reserved for future use.
AUX
LCC0 and
LCC4 through LCC7 on a TX-CIP are reserved
TX-CIP-1 Port and Destination
LCC0 — T-CB-1 in LCC0
LCC1 — T-CB-1 in LCC1
LCC2 — T-CB-1 in LCC2
LCC3 — T-CB-1 in LCC3
LCC1 are presented
