CHAPTER 20
Integrating an Operational T640 Router
with the TX Matrix Router
Overview of Integrating an Operational T640 Router with the TX Matrix Router
Copyright © 2010, Juniper Networks, Inc.
Overview of Integrating an Operational T640 Router with the TX Matrix
Router on page 169
Tools and Parts Required for Integrating an Operational T640 Router with the TX Matrix
Router on page 170
Converting and Connecting the Control Planes Between an Operational T640 Router
and the TX Matrix Router on page 171
Integrating the Switching Planes Between an Operational T640 Router and the TX
Matrix Router on page 174
NOTE: Only the first T640 router that you integrate with the TX Matrix router
can be operational. Additional T640 routers you integrate must be offline.
During the integration of an operational T640 router with the TX Matrix router, the T640
router continues to pass traffic until it is rebooted. The traffic interruption during the
reboot is comparable to the interruption that occurs during a Junos OS major upgrade.
NOTE: During the conversion and connection of the switching planes, the
T640 router might experience some packet loss, depending on the operational
environment. For more information, contact your customer support
representative.
To convert and connect a switching plane of an operational T640 router:
Verify that the fiber-optic array cables have been routed between the TX Matrix router
1.
and the T640 router.
See "Routing the TX Matrix Fiber-Optic Array Cables" on page 111.
Verify that the the fiber-optic array cables have been tested and connected to the
2.
TX Matrix router.
169
