To connect the cables to network devices:
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to one of the ESD points on the chassis.
Plug one end of a UTP Category 5 Ethernet cable (Figure 65 on page 118 shows the
2.
connector) into the
ETHERNET
connects to the Routing Engine in the upper Routing Engine slot (
Plug the other end of the cable into the network device.
3.
Plug one end of another UTP Category 5 Ethernet cable into the
4.
TX-CIP-1. This port connects to the Routing Engine in the lower Routing Engine slot
(
).
RE1
Plug the other end of the cable into the network device.
5.
Figure 65: Routing Engine Ethernet Cable Connector
port on
TX-CIP-0
(see Figure 66 on page 119). This port
Copyright © 2010, Juniper Networks, Inc.
).
RE0
ETHERNET
port on
