the optics in these components, as well as the loopback connector and
adapter dust covers, immediately before connecting them. For cleaning
instructions, see "Cleaning the TX Matrix and T640 Fiber-Optic Components
Overview" on page 200.
To install a fiber-optic array cable:
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to one of the ESD points on the chassis.
Using the supplied label sheets, attach a label to each end of the replacement
2.
fiber-optic array cable to help you identify the corresponding TX-SIB adapter and
T640-SIB. The labels are marked with the chassis ID and the switching plane
(separated with a slash). For example, use the label marked
connection between adapter
22 on page 112 lists the connections between TX-SIBs and T640-SIBs.
NOTE: You must use the same length for every fiber-optic array cable
from a particular T640 router to the TX Matrix router. However, you do
not need to use the same length for all fiber-optic array cables within a
routing matrix.
Route the end of the fiber-optic array cable that plugs into the TX-SIB over the
3.
TX Matrix router to the TX-SIB adapter. If you have installed the optional cable shelf
assembly, use the lowest shelf to support a cable destined to any TX-SIB adapter
labeled , use the next shelf up to support a cable destined to any TX-SIB adapter
LCC0
labeled , and so on (see Figure 64 on page 116).
LCC1
NOTE: If you have previously routed a spare fiber-optic array cable
between the TX Matrix router and T640 router, some of the steps in this
procedure have already been performed.
CAUTION: You must maintain a minimum bend radius of 2 in. (5.1 cm).
We recommend that you maintain a bend radius of 10 in. (25.4 cm). If you
must bend a fiber-optic array cable to a 2-inch radius, we recommend
that you do not use more than two such bends.
CAUTION: Plastic wrap-ties can damage or crimp the fiber-optic array
cables (see Figure 117 on page 264). We recommend that you use soft band
straps to secure fiber-optic array cables.
Chapter 24: Replacing TX Matrix Hardware Components
on and
LCC0 TX-SIB-2 T640-SIB-2
0/2 to identify a
in router . Table
LCC0
