TX Matrix Two-Input 160-A DC Power Supply LEDs

Table 14: Two-Input 160-A DC Power Supply LEDs

LED Color
CB OK Green
Yellow
CB TRIP
Yellow
OVER TEMP
Copyright © 2010, Juniper Networks, Inc.

Table 13: Fault Tolerance

Redundancy
Nonredundant power
supplies
Redundant power supplies
TX Matrix Power System Description on page 41
TX Matrix Two-Input 160-A DC Power Supply LEDs on page 43
Installing a TX Matrix Two-Input 160-A Power Supply on page 272
Maintaining the Power Supplies on page 203
TX Matrix DC Power Supply Specifications on page 338
Four LEDs on each two-input 160-A DC power supply faceplate indicate the status of
the power supply. In addition, a power supply failure triggers the red alarm LED on the
craft interface. Table 14 on page 43 describes the functions of the power supply LEDs.
State
On steadily
Off
On steadily
Off
On steadily
Off
Chapter 3: TX Matrix Hardware Components Overview
Fault Tolerance When One Input Fails or Is Disconnected
If either input fails, the router shuts down.
NOTE: We recommend that you install redundant power supplies.
If either input on one power supply fails, the other power supply
assumes the electrical load for both inputs. If one of the inputs on
the other power supply is not functional, the router shuts down.
Description
Circuit breaker is on.
Circuit breaker is off.
Circuit breaker is not turned on, or host subsystem
has detected a failure and has turned the circuit
breaker off.
No problems have occured with circuit breaker, or
the power supply is off.
Power supply has exceeded recommended
temperature.
Power supply is within the recommended
temperature or is not turned on.
