TX Matrix Hardware Guide
268
PFE #0 : Links ok
PFE #1 : Links ok
SCC : Links ok
SIB #2
plane state: S_ACTIVE
FPC #0
PFE #0 : Links ok
PFE #1 : Links ok
SCC : Links ok
SIB #3
plane state: S_ACTIVE
FPC #0
PFE #0 : Links ok
PFE #1 : Links ok
SCC : Links ok
SIB #4
plane state: S_ACTIVE
FPC #0
PFE #0 : Links ok
PFE #1 : Links ok
SCC : Links ok
Verify that the state of each link is
If the state of all TX-SIBs, T640-SIBs, and links displayed in Step 1 through Step 2 is
3.
correct, the connections between the TX-SIBs and the T640-SIBs are operating
correctly. If the state is incorrect, bring the interface connected by the fiber-optic array
cable offline, remove the cable, and clean the TX-SIB and T640-SIB adapters and
the cable connectors plugged into them:
To bring the interface offline:
Issue the following CLI command:
user@host> request chassis sib slot slot-number lcc lcc-number offline
The slot number can be from 0 through 4 and corresponds to the TX-SIB chassis
slot. The LCC number can be 0 through 3 and corresponds to the TX-SIB adapters
labeled through
LCC0
Press and hold the online/offline button next to the TX-SIB adapter until the
LED is not lit.
Press and hold the online/offline button on the T640-SIB faceplate until the
LED is not lit.
To remove a cable connector, partially loosen its thumbscrew and captive screw.
(Use the supplied small slotted screwdriver to loosen the captive screw.) Alternate
between the thumbscrew and the hex screw until the cable connector is removed
from the adapter.
For instructions about cleaning the TX-SIB adapter, T640-SIB adapter, and
fiber-optic array cable connectors, see "Cleaning the TX Matrix and T640 Fiber-Optic
Components Overview" on page 200.
Reconnect the fiber-optic array cable to the TX-SIB and T640-SIB adapters as
4.
described in "Installing a TX Matrix Fiber-Optic Array Cable" on page 262.
.
Links ok
.
LCC3
