Replacing a Cable Restraint on a TX Matrix Three-Input 240-A DC Power Supply
Removing the Standard Cable Restraint From a Three-Input 240-A Power Supply
Copyright © 2010, Juniper Networks, Inc.
NOTE: After a power supply is powered on, it can take up to 60 seconds
for status indicators—such as the LEDs on the power supply, the command
output displays, and messages on the LCD display on the craft
interface—to indicate that the power supply is functioning normally. Ignore
error indicators that appear during the first 60 seconds.
Verify that the LEDs on the power supply faceplate are lit steadily, indicating
CB ON
5.
that the circuit breakers are on.
Verify that the DC OK LED on the power supply faceplate is lit steadily, indicating that
6.
the power supply is correctly installed and is functioning properly. The
blinks momentarily, then lights steadily.
TX Matrix Three-Input 240-A Power Supply Overview on page 44
TX Matrix Three-Input 240-A Power Supply LEDs on page 46
TX Matrix Preventing Electrostatic Discharge Damage on page 298
Each three-input 240-A power supply is shipped with the standard cable restraint shown
in Figure 130 on page 284. Two optional cable restraints are shipped in the accessory box.
If your DC power cables are too large or inflexible to fit into the standard cable restraint,
we recommend that you remove the standard cable restraint and install the optional
cable restraint (see Figure 131 on page 284) on each three-input 240-A power supply.
NOTE: Before you remove a chassis from a rack or cabinet, you must remove
the optional cable restraint from the three-input 240-A power supply.
Removing the Standard Cable Restraint From a Three-Input 240-A Power
1.
Supply on page 283
Installing the Optional Cable Restraint on a Three-Input 240-A Power
2.
Supply on page 284
The cable restraint is located on the right edge of the power supply faceplate. To remove
the standard cable restraint:
Loosen the captive screw on the standard cable restraint or captive screws on the
1.
optional cable restraint.
Remove the cable restraint from the power supply.
2.
Chapter 24: Replacing TX Matrix Hardware Components
LED
DC OK
283
