Grounding And Providing Power To The Tx Matrix Plus Router; Overview Of Installing Tx Matrix Plus Grounding And Power; Tools And Parts Required For Connecting The Tx Matrix Plus Router To Ground - Juniper TX MATRIX PLUS Hardware Manual

CHAPTER 13
Grounding and Providing Power to the TX
Matrix Plus Router

Overview of Installing TX Matrix Plus Grounding and Power

Copyright © 2010, Juniper Networks, Inc.
Overview of Installing TX Matrix Plus Grounding and Power on page 165
Tools and Parts Required for Connecting the TX Matrix Plus Router to Ground and
Power on page 166
Grounding the TX Matrix Plus Router on page 166
Providing Power to a Seven-Input 420-A Power Supply on page 167
Powering Off the TX Matrix Plus Router on page 173
To ground and provide power to the TX Matrix Plus router:
Read the safety guidelines and warnings for working with electricity.
1.
"TX Matrix Plus General Electrical Safety Guidelines" on page 414
"General Electrical Safety Warnings for M Series, MX Series, and T Series Routers" on
page 417
"TX Matrix Plus DC Power Electrical Safety Guidelines" on page 421
"DC Power Electrical Safety Warnings for M Series, MX Series, and T Series Routers"
on page 422
Gather the tools for connecting to ground and power.
2.
"Tools and Parts Required for Connecting the TX Matrix Plus Router to Ground and
Power" on page 166
Connect the grounding cable to the TX Matrix Plus router.
3.
"Grounding the TX Matrix Plus Router" on page 166
Connect the DC power cables to the power supplies, and power on the TX Matrix Plus
4.
router..
"Providing Power to a Seven-Input 420-A Power Supply" on page 167
165
