TX Matrix Hardware Guide
220
If the statement is included at the
3. online-expected
level, delete it:
user@host# delete chassis lcc 0 online-expected
Issue the
commit synchronize
4.
errors:
user@host# commit synchronize
Take the T640 router offline:
5.
user@host> request chassis lcc slot 0 offline
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
6.
the strap to one of the ESD points on the chassis.
Remove the control plane connections between the TX-CIPs and the T-CBs:
7.
Disconnect the Ethernet cable plugged into the port labeled
a.
Disconnect the other end of the Ethernet cable plugged into the port labeled
b.
on .
T-CB-0
Disconnect the Ethernet cable plugged into the port labeled
c.
Disconnect the other end of the Ethernet cable plugged into the port labeled
d.
on T-CB-1 .
Remove the fiber-optic array cable connector from each T640-SIB adapter. Partially
8.
loosen the thumbscrew and captive screw on the fiber-optic array cable connector.
(Use the supplied small slotted screwdriver to loosen the captive screw.) Alternate
between the thumbscrew and captive screw until the cable connector is removed
from the adapter.
Remove the dust covers from the dust-free resealable plastic bag and reinstall them
9.
on the fiber-optic array cable connectors. Align the dust cover with the cable connector
and carefully press them together until they stop. The cover and the cable connector
are keyed to ensure proper mating. Secure the dust cover by tightening the thumbscrew
and captive screw on the connector. (Use the supplied small slotted screwdriver to
tighten the captive screw.)
Dress the fiber-optic array cables so that they are not touching or blocking access to
10.
T640 router components, and that they do not drape where people could trip on
them.
Replace each T640-SIB with a SIB. Use the standard replacement procedure described
11.
in the T640 Core Router Hardware Guide.
Do not bring any of the SIBs online.
NOTE: Ensure that the ejector handle tabs are properly mated inside their
corresponding chassis slots before you tighten the captive screws on the
ejector handles. You might have to close and open the handles a few times
before the tabs catch the slots.
[edit chassis lcc number]
command, and ensure that there are no synchronization
Copyright © 2010, Juniper Networks, Inc.
hierarchy
on .
LCC0 TX-CIP-0
CIP
LCC0 on TX-CIP-1 .
CIP
