Chapter 4
NETWORK SETUP MENU

ETHERNET PARAMS

ETHERNET
PARAMS
(from page 87)
NetBIOS ASCII
Protocol Data Port
Enable* 9100*
Disable 1023 - 65535
The ETHERNET PARAMS menu helps your printer communicate on a
network.
For information on assigning the IP Address, Gateway Address, Subnet
Mask, and MAC Address, refer to the Network Interface Card User's Manual .
NetBIOS Protocol
This option determines whether the NetBIOS protocol will be available. The
selections are as indicated below:
•
Enable (default). Makes the NetBIOS protocol available with the ethernet
installed.
•
Disable. Makes the NetBIOS protocol unavailable during printer
operation.
ASCII Data Port
This option sets the port number for ASCII print jobs. The data port number
needs to match your host system setting.
•
9100 (default)
•
1023 - 65535
IPDS Data Port
This option allows you to set the port number for IPDS print jobs only if the
IPDS option is installed.
The range is 1023 - 65535, and the default is 5001.
Keep Alive Timer
This is the time that the Keep Alive Timer will run. With the Keep Alive Timer
on, the tcp connection will stay connected even after the print job has
terminated.
•
3 Minutes (default)
•
2 - 10 Minutes
92
IPDS Data Keep Alive
Port Timer
5001* 3 Minutes*
1023 - 65535 2 - 10 Minutes
* = Factory Default
Ethernet Job Control
Speed
Standard*
Auto Select*
10 Half Duplex Enhanced
10 Full Duplex Off
100 Half Duplex
100 Full Duplex
