Chapter 3
Operational Procedures
Platen Lever
28. Turn the Auto Platen Stop Knob clockwise or counterclockwise to match
the paper thickness. (The A-B-C scale corresponds approximately to 1-,
3-, and 6-part paper thickness. Adjust until you have the desired print
quality).
NOTE: The platen stop allows you to set an optimum and consistent
29. Lower the platen lever until it stops.
30. Press ON LINE/CLEAR to clear any fault messages (such as "LOAD
PAPER") from the LCD.
31. Press SET TOF. The top-of-form you have set moves down to the print
position. If there is data in the buffer, the paper moves forward to the last
print position on the next page.
32. Press ON LINE/CLEAR and close the printer cover.
38
Vertical Position
Knob
A
Platen
Stop
Figure 15. Adjusting the Platen Lever
thickness that is not affected when opening and closing the platen
lever.
Paper Thickness
Indicator
A
Platen Stop
Knob
