Peri VARIOKIT VBC Assembly Instructions Manual page 71

Hydraulics VBC
Art no. Weight [kg]
115581 10.280 Service Box Hydraulics
Consisting of:
1 pc. 115590 Tool Box 580x260x285mm
6 pc. 115583 Pressure Gauge Typ 570 VA-Geh.
6 pc. 115584 Hose MKT 6-02 DN 02
12 pc. 115582 Measuring Coupl. SMK 20-G 1/4-PC
2 pc. 115591 Double Spanner SW10x13
1 pc. 115592 Double Spanner SW13x17
1 pc. 135172 Double Spanner SW19x22
1 pc. 115588 Double Spanner SW19x24
1 pc. 051778 Double Spanner SW24x27
1 pc. 115589 Double Spanner SW27x32
1 pc. 057278 Allen Key Set 8 pcs.
1 pc. 115585 Allen Key SW12
1 pc. 057279 Allen Key SW14
1 pc. 057282 Pipe Wrench
1 pc. 115147 Angle Fitting Set PS
2 pc. 115396 Fitting Set PS RCS short
1 pc. 072180 Ratchet Wrench 1/2"
20 pc. 123881 Tube Screw Plug ROV12SX
20 pc. 123880 Threaded Plug VKAN 12S VIT
100 pc. 051760 Cable Binder NT-240H
2 pc. 126425 Distance Piece Ø120mm coat
1 pc. 126440 Socket SW17 1/2"
1 pc. 135173 Allen Key SHR-Bit SW05
1 pc. 135174 Allen Key SHR-Bit SW06
1 pc. 135175 Allen Key SHR-Bit SW08
1 pc. 135176 Allen Key SHR-Bit SW10
1 pc. 135177 SHR Screwdriver Bit 6 parts Slot/PH
2 pc. 711035 PERI Label 128x65mm
1 pc. 126434 List of contents Hydraulic Service Case
