Components Used - Peri VARIOKIT VBC Assembly Instructions Manual

A3 Hydraulic system

Components used

As a rule, the following components are used. Take the project-specific documentation into account!
Reference Designation
Manufacturer (e.g.)
Type (e.g.)
1R/1L Front main cylinder
Weber
LD28-180/110-150-FWF-000
2R/2L Drive cylinder
Weber
LD28-120/70-650-FWF-000
3R/3L Rear main cylinder
Euro Press Pack
COF083N200X1
4R/4L Lifting and lowering cylinder
5R/5L Euro Press Pack
COF034N250X1
6 Pre-tensioning jack
Euro Press Pack
CMF60N75
7 Hydraulic hand pump
Weber
PN141
Nominal load details without pressure and friction loss
VBC Balanced Cantilever Hydraulic System – Hydraulic System and Standard Cycle
Assembly Instructions
Nominal load
Pressing Pulling
at 280 bar at 280 bar
713 kN 446 kN
316 kN 209 kN
574 kN –
235 kN –
Area
Piston side Piston rod
side
254.5 cm 159.4 cm
2 2
113.1 cm 74.6 cm
2 2
205.0 cm –
2
84.2 cm –
2
Article
132243
132244
132245
132246
132249
132250
21
