B2 Anchoring/height adjustment

General

Height adjustment
The height of the front suspension of
the slab formwork is adjusted using the
pre-tensioning jack and hand pump in
the same way as described below.
Anchoring
Release the anchoring, e.g. for slab
formwork, bottom slab formwork, para-
pet formwork, according to project-spe-
cific documentation.
Warning
Incorrect operation or hydraulic damage
can cause unforeseen movements of
the components.
As a result, body parts could become
trapped and crushed.
⇒ While the domed nut is being fitted,
no other work is to be carried out on
the anchoring.
⇒ Do not change the switch status of
the hydraulic system.
⇒ Do not insert hands between clamp-
ing points.
■
Do not exceed the permissible
pre-tensioning force for each respec-
tive tie rod. See table. B2.01
■
Follow Instructions for Use from the
hand pump manufacturer!
VBC Balanced Cantilever Hydraulic System – Hydraulic System and Standard Cycle
Assembly Instructions
Pressure conversion
Valid for EUROPRESS cylinder CMF60N75 (art. no.: 132249)
Pre-tensioning force
[kN]
50
100
150
200
250
300
350
400
450
500
550
590
Tab. B2.01
Pre-tensioning jack pressure
[bar]
59
119
178
237
297
356
415
475
534
593
653
700
