Overview
Main components
4
8
B5
B2
Top slab formwork
B3
Bottom slab formwork
B4
Front carriage
B5
Rear carriage
2
Front Main Cylinder VBC 280
3
Driving Cylinder VBC 280
4
Rear Main Cylinder VBC 280
5
Lifting and Lowering Cylinder VBC 280
6
Pre-Tensioning Jack-2 VBC (not shown)
7
Hand Pump-2 VBC (not shown)
8
Rail VBC
4
3
2
B4
VBC Balanced Cantilever Hydraulic System – Hydraulic System and Standard Cycle
5
B2
B3
