Component overview

Pos. no. Component name
1 Hydraulic Unit VBC 280
2
Front Main Cylinder VBC 280
3 Drive Cylinder VBC 280
4 Rear Main Cylinder VBC 280
5 Lifting and Lowering Cylinder VBC 280
6 Pre-Tensioning Jack-2 VBC
7 Hand Pump-2 VBC
8 Rail VBC
9 Chuck VBC
10 Cylinder Table VBC
21 Drive Catch Head-2 VBC
23 Main Frame Chord VBC
24 Main Frame Post VBC
25 Rear Carriage Tube VBC
26
Rear Carriage Rocker VBC
27 Rear Cylinder Head VBC
28 Hold-down Bracket VBC
29
Sliding Plate VBC
30 Post Base VBC
31 Front Carriage VBC
32
Head Pawl Pin VBC
33 Lifting Shim VBC 20
34 Lifting Jack Bracket VBC
35 Lifting Counterplate VBC
36 Roller Block VBC
51 Auxiliary tie rod
52 Anchor tie rod
53 Main tie rod
61
Tie nut straight
62 Domed nut
63 Main tie nut
64
Hexagonal coupler
16
Article no.
132242
132243
132244
132245
132246
132249
132250
128997
129660
134596
129108
129100
129068
129078
129091
129641
129642
129083
129077
129003
129612
129609
129614
129009
130598
