Peri VARIOKIT VBC Assembly Instructions Manual page 69

Hydraulics VBC
Art no. Weight [kg]
1.370 Hydr.T-Piece 2SN-DN08-FF
129423
Consists of
1 pc 128992 Pin ISO16028 DN10 R3/8IG
2 pc 128993 Sleeve ISO16028 DN10 R3/8IG
3 pc 051750 Male STUD Coupl. X-GE12PSR-ED
Art no. Weight [kg]
112421 3.000 Hydr. Accum. Piece RCS
To double the volume of the oil at the Hydraulic Pump RCS. Also doubles the speed of the Hydraulic Winch RCS.
Art no. Weight [kg]
137400 0.350 Hydr.Hose 2SN DN8 65 90°
Art no. Weight [kg]
137346 0.007 Cable Binder 7,8x540mm
1222
.
69
