Power Switch

The power switch is also located on the left side of the front panel as part of the power
switch/LCD assembly. Use the power switch to power the workstation on and off.
When you press the power switch to power off the workstation, the operating system
executes an automatic shutdown -q command. This prevents any damage to programs
and data on the system disk.
Pressing the power switch on again automatically boots up the HP-UX operating system, if
the system has been configured to auto boot. For information on setting auto boot, refer
to the section "Setting the Auto Boot and Auto Search Flags" on page 158.

Internal Storage Devices

The B2000 workstation supports the following internal storage devices:
• Up to two hard disk drives
• One CD drive
• Optionally, one floppy disk drive
The following subsections describe these internal storage devices.
Hard Disk Drives
The B2000 workstation has one 9 GB 7200 RPM Ultra2 Wide Low-Voltage Differential
(LVD) SCSI hard disk drive as a standard component. Optionally, the workstation also
supports a second 9 GB 7200 RPM Ultra2 Wide LVD SCSI hard disk drive.
CD Drive
The B2000 workstation has one ATAPI fast CD drive as a standard component. Figure 1-3
shows the operating features of the CD drive, and Table 1-2 describes these features.
NOTE The B2000 workstation supports one CD drive only.

Figure 1-3. CD Drive Features

Disk
Tray
Headphones
Jack
Chapter 1
Emergency
Eject Hole
Busy
Audio
Indicator
Control
Thumbwheel
Product Information
Front Panel Components
Eject
Button
