2. Push the security loop's pin into the security loop pin hole, and insert the padlock's latch
through the holes at the top and bottom of the security loop. This locks the left side
panel.
3. Lock the padlock. The workstation's left side panel is now secure.

Power Cord Connector

Plug the workstation's power cord into the power cord connector to provide AC power to
the system.

Monitors

The B2000 workstation supports monitors set to one of the following resolutions:
• 1280×1024 color (stereo capable), 75Hz, VESA
• 1600×1200 color, 75Hz, VESA
• 1280×1024 color, 75 Hz, VESA
The workstation must have either an HP-supported monitor running at 75 Hz with a
1280×1024 resolution, or a full multi-mode color monitor. Monitors with EVC, D-Sub, or 5
BNC connectors (RGB, vertical sync, horizontal sync) will function.
The HP V
NOTE
types that use a sync on green signal. This includes monitors such as the
HP 1097A/B/C/D, A2088A, and A2828A/B that only have 3 BNC connectors.
Note that you can connect the B2000 workstation to earlier HP monitors with 15-pin
miniature D-Sub cables using the A4168A adapter shipped with the workstation's
accessory kit.
Before using a monitor, you should become familiar with its controls, connectors, and
indicators. For information about using a monitor, see the documentation that came with
the monitor.
Chapter 1
-fxe graphics card will not function with older HP monitor
ISUALIZE
Product Information
Monitors
27
