Closing the Left Side Panel
Perform the following steps to close the left side panel:
1. Hold the left side panel so that the top and bottom hinge hooks can be inserted into
their hinge slots. See Figure 4-3. Note that the hinge slots are located on the far right
edge of the workstation (using the rear of the workstation as the reference).
2. Swing the rear edge of the left side panel toward the rear of the workstation and press
the outside edges of the left side panel tightly against the workstation. This will ensure
a tight seal of the EMI gasket.
3. Secure the left side panel in place by tightening the two T-15 Torx thumbscrews you
previously removed into the workstation's rear panel.
Chapter 4
Field Replaceable Units
FRU Removal and Replacement
89
