Field Replaceable Units
FRU Removal and Replacement
Replacing the I/O Fan
Perform the following steps to replace the I/O fan:
1. Install the I/O fan into the fan/speaker mounting bracket by pulling out on the left and
right fan mounting clips, inserting the fan, and then releasing the fan mounting clips so
that they hold the fan in place. See Figure 4-52.
2. Align the fan/speaker mounting bracket in the chassis, holding the fan and speaker
cable to the card guide edge of the mounting bracket. Then rotate the fan/speaker
mounting bracket into place while holding up on the retainer tab.
3. Connect the I/O fan and speaker cables to the system board.
4. Place the air divider within the chassis and screw in the two T-15 Torx screws that hold
the air divider in place. See Figure 4-51.
5. Replace all I/O cards and the PCI retainer clip as explained in the section "Replacing or
Installing I/O Cards" on page 112.
6. Close the left side panel of the workstation as shown in the section "Closing the Left
Side Panel."
Removing the System Fan
Perform the following steps to remove the system fan:
1. Open the left side panel of the workstation as shown in the section "Opening the Left
Side Panel."
2. Remove the four plastic pop rivets at the corners of the system fan to release the fan
from the rear panel of the workstation chassis.
3. Disconnect the system fan's power cable from the system board and remove the fan.
Replacing the System Fan
Perform the following steps to replace the system fan:
1. Align the flow arrow on the system fan so that it is pointing toward the rear panel of the
workstation chassis.
2. Position the fan flush with the rear panel of the workstation and insert the four plastic
pop rivets to secure the fan to the rear panel.
3. Connect the system fan's power cable to the system board.
4. Close the left side panel of the workstation as shown in the section "Closing the Left
Side Panel."
126 Chapter 4
