Express-ID7 User's Guide PICMG COM.0 R3.1
Power Consumption
Please contact your ADLINK representative for the document "COM Express Module Power Consumption".

2.10. Mechanical and Environmental

Form Factor and specification
PICMG COM Express Rev 3.1 (COM.0 R3.1), Type 7, Basic size 125 x 95 mm
Operating Temperature
Standard 0°C to 60°C Storage: -20°C to 80°C
Extreme Rugged -40°C to 85°C Storage: -40°C to 85°C (build option by project basis, selected SoC SKUs, TBC)
Humidity
5-90% RH operating, non-condensing, 5-95% RH storage (and operating with conformal coating)
Shock and Vibration
IEC 60068-2-64 and IEC-60068-2-27
MIL-STD-202F, Method 213B, Table 213-I, Condition A and Method 214A, Table 214-I, Condition D
HALT tested
Thermal Stress, Vibration Stress, Thermal Shock and Combined Test
