Canon imagePROGRAF PRO-6600 Online Manual page 932

Space for installation (W x D x
H)
PRO-2600 / PRO-526
Power supply
Power consumption
Operating environment
Dimensions (W x D x H)
Weight
Space for installation (W x D x
H)
Printer and Stand (when using basket: basket position 1) *:
Approx. 78.5 x 66.3 x 61.5 in. (1993 x 1684 x 1560 mm)
* For details on the Basket Position, see
100-240 V AC (50/60 Hz)
When printing (wired LAN connection): Approx. 85 W
Standby (wired LAN connection): Approx. 1.7 W
Standby (all ports connected): Approx. 2.2 W
When power is off: Approx. 0.1 W *1
*1 The printer uses a trace amount of power even when turned off. To stop all
power consumption, turn off the printer and unplug the power cord.
Temperature: 59 to 86 °F (15 to 30 °C)
Humidity: 10 to 80 % RH (with no condensation)
Printer only:
Approx. 43.8 x 28.9 x 24.8 in. (1110 x 734 x 628 mm)
Printer and Stand (when basket is not used):
Approx. 43.8 x 30.2 x 46 in. (1110 x 766 x 1168 mm)
Printer and Stand (when using basket: basket position 1) *:
Approx. 43.8 x 38.8 x 46 in. (1110 x 984 x 1168 mm)
Printer and Stand (when using basket: basket position 2/4/5) *:
Approx. 43.8 x 48.2 x 46 in. (1110 x 1222 x 1168 mm)
Printer and Stand (when using basket: basket position 3) *:
Approx. 43.8 x 56.5 x 46 in. (1110 x 1434 x 1168 mm)
* For details on the Basket Position, see
Stand may not be provided depending on the region where the printer is
purchased.
Printer only (without print head and ink tanks):
Approx. 187 lb (85 kg)
Stand and basket: Approx. 37 lb (17 kg)
Roll unit: Approx. 37 lb (17 kg)
Printer only:
Approx. 59.5 x 56.5 x 40.2 in. (1510 x 1434 x 1020 mm)
Printer and Stand (when using basket: basket position 1) *:
Approx. 59.5 x 66.3 x 61.5 in. (1510 x 1684 x 1560 mm)
* For details on the Basket Position, see
932
Example Basket Configurations.
Example Basket Configurations.
Example Basket Configurations.
