Home Screen Menu Composition

After the printer starts up, the HOME screen appears on the touch screen.
From the HOME screen, you can check the printer status and select the maintenance, paper operations,
settings, and other menus.
Basic Touch Screen Operations
Icons on Touch Screen
A: Printer Information Display Area
Displays the printer status, messages, and other information. Select this item when a message appears
to view the message on the list screen and to jump to the screen with detailed information and
operations.
Notification Messages
B: Network
Displays the current network status. Select to display the basic network information or to change the
network settings.
The icon differs depending on the network of use or the network status.
Wi-Fi is enabled and the printer is connected to the wireless router.
Note
• • Depending on the signal state, the icon will change.
(Signal strength: 81 % or more): You can use the printer over a Wi-Fi without any problems.
(Signal strength: 51 % or more): The problem such as the printer cannot print may occur
according to the network status. We recommends placing the printer near the wireless router.
