K: Touch Screen
Use this screen to operate the printer and check the printer status.
Operation Panel
L: Ink Tank Cover
Open this cover to replace the ink tank.
Ink Tank Cover (Inside)
Roll Holder Set
Load roll paper on the roll holder and then load the holder in the printer. You can use the roll holder with
both 2-inch and 3-inch paper cores. However, if using 3-inch core roll paper, attach the 3-inch paper core
attachment.
Loading Rolls on the Roll Holder
• PRO-6600 / PRO-566 : Roll Holder Set RH2-66
• PRO-4600 / PRO-546 : Roll Holder Set RH2-46
• PRO-2600 / PRO-526 : Roll Holder Set RH2-29
◦ ◦ Roll Holder (for 2- and 3-inch paper cores)
◦ ◦ 3-Inch Paper Core Attachment (x2)
Maintenance Cartridge
Model number: MC-30
Absorbs ink used for cleaning.
Replacing the Maintenance Cartridge
