3.
3. Grasp Belt and insert Belt Stopper into position shown.
Important
• Attach the Belt Stopper that was removed and stored after initial installation. Neglecting to
attach the Belt Stopper may damage the printer.
•
• Do not touch the linear scale (A), carriage shaft (B), or ink tube stabilizer (C). Touching these
may cause malfunction.
4.
4. Close top cover.
573
