to avoid spilling ink and staining your clothes or the surrounding area. If ink accidentally spills,
wipe off the ink with a dry cloth.
• If you need to put a print head somewhere temporarily before installation, do not set it down
with the nozzles and metal contacts facing down. If the nozzles or metal contacts are damaged,
it may affect the printing quality.
• Do not reattach the removed protective part. Dispose of these materials in accordance with
local regulations.
15.
15. Turn ink holes (J) toward the front and insert print head into carriage.
Insert the print head all the way into the carriage, while taking care to keep parts that were protected
by the protective caps from touching the carriage.
16.
16. Grasp tab (F) of print head locking cover and lower it to front to lock print head.
539
