Using The Usb Interface - Kemper KHS Mini System Control Installation And Operating Instructions Manual

8.1.5

Using the USB interface

With the USB interface of the KHS Mini System Control -MASTER 2.0-, it is possible to copy the
journal (CSV file), the configuration of the system controls (CFG file) and the datalog (CSV file) onto a
USB memory stick. Furthermore, backed-up configurations (CFG file) and new software updates (UPD
file) can be written to the KHS Mini System Control -MASTER 2.0-. The functions are simulated in
Illustration 8.49.
Copying the
journal
Copy the configuration
Read-in the configuration
Copy datalog
Software update
Webserver update
Ill. 8.49 Overview USB menu
Manual KHS Mini System Control
Note:
The USB menu is not visible in normal
mode. The menu
activated when a USB memory stick is
connected to the KHS Mini System
Control -MASTER 2.0-.
Note:
After selecting a menu item, follow the
instructions on the subsequent display.
43
is automatically
