Kemper KHS Mini System Control Installation And Operating Instructions Manual page 50

Date / Time
Network
Function external switch
Other settings
Manual KHS Mini System Control
The current time and current date of the KHS Mini System Control -
MASTER 2.0- are displayed in the grey boxes. To set the system control
time, click on the APPLY DATE/TIME
control to apply the date and time settings of, e.g. your PC. The KHS Mini
System Control -MASTER 2.0- can independently switch between
daylight savings and standard time. If you do not want this setting, click
the button. If the button is set to
daylight savings and standard time is not automatic.
To establish a connection between the PC and the KHS Mini System
Control -MASTER 2.0- with a WEB browser, in the boxes IP address,
Subnet, Gateway, prim. DNS and sec. DNS enter the required network
configurations.
Note:
You can obtain the corresponding parameters for
linking in your network from your system administrator.
The following parameters are configured as factory
defaults:
IP address: 10.1.23.150
Subnet:
Gateway:
With the KHS Mini System Control -MASTER 2.0- it is possible to switch
between two flushing programs. The programs can be configured in the
operating modes menu interface and the individual system controls can
be added (see Chapter 8.2.4). If the button for the program switchover is
set to , the external program switching is deactivated. If the button for
the program switchover is set to
active. The names of the flushing programs can be changed with an entry
in the related box. Use the "Current operating mode" dropdown list to
manually switch the flushing programs in the WEB browser and to block
them for maintenance purposes. Use the "External input" dropdown list to
set the operating mode of the external input.
Maintenance:
The two mentioned flushing programs can be switched
with the WEB browser and can be blocked for
maintenance purposes.
The KHS Mini System Control -MASTER 2.0- can activate an internal
buzzer in case of faults. If the related button displays
buzzer is activated. If the related button displays
not activated. Furthermore, the language can be changed with the
dropdown menu.
47
button. That causes the system
, the switchover between
255.255.255.0
10.1.23.1
, the external program switching is
, the alarm buzzer is
, the alarm
