The following configuration steps are discussed based on the sample project from Illustration 8.1
(Page 17). For an overview of the system commissioning, Illustration 8.52 is presented.
Ill. 8.52 Overview for the system commissioning of the sample project
Manual KHS Mini System Control
To the KHS Mini System Control -
MASTER 2.0-, the related KHS Mini-
System Control –SLAVE- is added at this
point. As long as no KHS Mini System
Control is added, it is grey. Based on the
serial number stated in the brackets, it
can be compared with the "Overview for
system commissioning".
To add a KHS Mini System Control, store
a meaningful name in the input box. Use
the APPLY NAME
selected system name. After successfully
storing the name, the selected KHS Mini
System Control is shown in yellow.
Based on this scheme, add all KHS Mini
System Control
-MASTER 2.0-.
49
button to transmit the
-SLAVEs- to the
