Input box
lines and to push empty lines to the back. The remaining input facilities in the lines are explained
below.
The following configuration steps are discussed based on the sample project from Illustration 8.1
(Page 17).
Ill. 8.53 Overview for the system commissioning of the sample project
Attention:
The selected lines and temperatures serve as examples. The values must always
be set for each building and for each type of use and medium so that
representative measurement values are generated and use as intended is
maintained for the system.
Configuration MASTER (datalogging)
Manual KHS Mini System Control
If a KHS Mini System Control is
selected
interface, the related input box
opens on the right side. Click
on the
ADD LINE
up to 16 lines to the TIMER.
Press the button to delete the
respective
TIMER. Click on the
TIMER
Select type
After adding a line with
the line type. The KHS Mini System
Control -MASTER 2.0- in the presented
sample project is connected to a KHS-
CONTROL-PLUS
valve. To record the flow measurement
valve measurement data at the same
time, the "Datalogging" line type has to be
selected from a dropdown list.
64
in
the
selection
button to add
lines
from
the
RESORT
to delete all deactivated
ADD LINE,
select
flow
measurement
