8.1.4
Main menu
The following chapters explain the functions of the "Main menu" interface of the KHS Mini System
Control -MASTER 2.0-. In the main menu there are the sub-menus: System settings, Can-bus setup,
Device settings, Operating modes, Journal, Switch program, Valve manual mode, Network setup (see
Ill. 8.7 and Ill. 8.8).
"Scroll back/forwards"
Selection of the submenu
1x "OK" Changes into the selected
submenu
1x "ESC" returns to the main
menu
Manual KHS Mini System Control
Ill. 8.7 Main menu "top"
Ill. 8.8 Main menu "bottom"
21
Scrollbar indicates the
position in the menu
