Configuration of SLAVE 1.4 (measurement)
Manual KHS Mini System Control
Select control type
Choose the available control types
that can be applied to the selected
KHS Mini System Control from a
dropdown list. The KHS Mini System
Control -SLAVE- 1.4 in this sample
project should act as a measure-
ment SLAVE.
Select sensor
The possible sensors are selected
from a dropdown list. In the sample
project being used, the KHS Mini
System Control -SLAVE 1.4- should
trigger a KHS Pt 1000 temperature
sensor.
Save settings
To effect the new parameters of the
input box, click the
CONTROL
settings.
56
WRITE IN
button to save the
