4.

Technical Data

Technical Data
Power supply 230 V AC 50/60Hz
Display Graphic display with background lighting
Operation with 4 buttons: Up | Down | Enter | Esc
Relay flush valve switching capacity 230 V, 2 A
Floating alarm relay, max. 230 V, 2 A
16 memory locations for the operating modes:
Time controlled water exchange
•
Temperature controlled water exchange
•
Volume controlled water exchange
•
Routine-time, routine-duration and routine-volume
•
Data logging
•
Release
•
For connecting:
1 ea. KHS-VAV-plus or KHS-VAV
•
1 ea. KHS-Temperature sensor Pt 1000
•
1 ea. KHS-Control Plus volume flow measurement valve
•
1 ea. KHS overflow monitor
•
1 detector circuit with up to 25 water sensors
•
Acoustic alarm signal in case of faults
Alarm acknowledgement on device
System is expandable: 1 -MASTER- with max. 62 - SLAVEs- via CAN bus
Leak safeguard through water sensor
Bus system connection per direction: CAN installation cable, max. 1000m total length
WEB-based PC-link for configuration and for reading out the flush log
Can save 50,000 journal entries
Datalogging up to 12 million entries
External switch | Switchover:
• Program 1 (e.g. school-holidays program)
• Program 2 (e.g. school program)
• Maintenance mode (system is blocked)
Menu driven operation in German, English or Dutch
Internal consumption 10 VA
Manual operation of the valves on the MASTER or via WEB browser
Ambient temperature range from 0 °C to 50 °C
Protection class IP 54
Surface mounted housing for wall installation
USB interface for updating the firmware, reading out the journal and data logging and
for downloading and uploading the configuration file
Network link through network cable (accessory)
Email in case of malfunctions possible
