6.3

Installation of network cable

Note:
The supplied network cable has a total length of 2.5m!
Step 1. Open the housing
Step 3. Secure cable
Manual KHS Mini System Control
Step 2. Route the cable through bottom
left into the housing
Step 4. Connect cable to the board
15
