AIE100-T2NX Series User's Manual
⚫ Reliable and Stable Design
The AIE100-T2NX adopts the advanced fanless system and supporting the PCIex4 NVMe
through M.2 interface, which makes it especially suitable for AI computing environments,
best for smart city, GPU-accelerated processing, edge computing and smart retail
applications.
⚫
JetPack Supported
The AIE100-T2NX supports JetPack 4.5.1 or later. NVIDIA JetPack SDK is the most
comprehensive solution for building AI applications.
JetPack supports Jetson AGX Xavier™, Jetson Xavier™ NX, Jetson™ TX2 NX,
Jetson™ Nano and Jetson TX2 series. It bundles all the Jetson platform software,
including TensorRT, cuDNN, CUDA Toolkit, VisionWorks, GStreamer, and OpenCV, all
built on top of L4T with LTS Linux kernel.
⚫
O.S. Supported
The AIE100-T2NX supports Linux Ubuntu 18.04.
⚫ Various Storage devices supported
For storage device, the AIE100-T2NX supports one M.2 2280 Key M with PCI-Express 2.0
x4 interface, an onboard 16GB eMMC 5.1 and one Micro SD interface.
1.2

System Specifications

1.2.1

Product Specification

⚫ NVIDIA Jetson SoM
NVIDIA® Jetson™ TX2 NX SoM
◼
⚫ CPU
◼
Dual-Core NVIDIA Denver 2 64-Bit CPU and Quad-Core Arm® Cortex® -A57
MPCore processor
⚫
GPU
256-core NVIDIA Pascal™ GPU
◼
⚫ Storage
◼
16GB eMMC 5.1 onboard
◼ One M.2 2280 M Key with PCI-Express 2.0 x4 NVMe SSD slot
◼ One Micro SD slot to support optional Micro SD card (UHS-I compatible)
⚫ System Memory
◼ One 4 GB 128-bit LPDDR4 onboard
⚫ WLAN & WWAN
◼
One PCI Express Mini Card modules slot to support Wi-Fi or 3G/4G/LTE modules
2 Introduction
