I/O boards
See figure 2-3. The transceiver modules on fiber optic I/O boards and the BNC
connectors on SDI/HD-SDI boards are identified as A through H . Each I/O board
is identified by the input and output numbers supported by the board position (1 - 8,
9 - 16, and so on).
Location A
I#1
O#1
O#2
Output and Input
OUT
IN
OUT
1a
A
ANAHEIM, CA
OUT
IN
OUT
1a
A
O#9
O#10
I#9
A
B
C
100-240V
50/60Hz 1.2A MAX.
I#26
I#25
I#27
Location A
2a
Input
Figure 2-3 — Arrangement of inputs and outputs on the I/O boards
Slot
Inputs and outputs
1
1 through 8
2
9 through 16
3
17 through 24
4
25 through 32
5*
33 through 40
6*
41 through 48
7*
49 through 56
8*
57 through 64
9*
65 through 72
* FOX 4G Matrix 7200 only
Locations A through H correspond to the input and output numbers identified
by the board position numbers. (For example, the input and output numbers
supported by the I/O board in location 9 - 16 are as follows: A = 9, B = 10, C = 11,
D = 12, E = 13, F = 14, G = 15, and H = 16.)
On the fiber optic I/O boards, locations A through H correspond to the transceiver
modules, each of which includes an input and an output. Therefore, locations A
through H are numbered from left to right.
On the SDI/HD-SDI I/O boards, inputs and outputs are grouped separately, with
inputs A through H on the left and outputs A through H on the right.
I#2
I#3
I#4
O#3
O#4
O#5
IN
OUT
IN
OUT
IN
1b
B
C
D
IN
OUT
OUT
IN
IN
1b
B
C
D
O#11
O#12
O#13
I#10
I#11
I#12
D
E
F
G
H
A
MUTI-RATE SDI INPUTS
PRIMARY POWER SUPPLY
I#28
I#30
I#32
I#29
I#31
O#25
Location H
Location A
2a
Input
Output
FOX 4G Matrix Switchers • Installation
I#5
I#6
I#7
O#6
O#7
O#8
OUT
IN
OUT
IN
OUT
IN
OUT
1a
1b
G
E
F
H
H
OUT
IN
OUT
IN
OUT
IN
OUT
1a
1b
E
F
G
H
O#14
O#15
O#16
I#13
I#14
I#15
I#16
B
C
C
D
D
E
E
F
F
G
G
H
H
MUTI-RATE SDI OUTPUTS
REDUNDANT POWER SUPPLY
O#26
O#28
O#30
O#32
O#27
O#29
O#31
2b
2b
Location H
I#8
Output and Input
IN
Slot 1
1
(1-8)
IN
Slot 2
1
(9-16)
Slot 3
No board
installed
Slot 4
2
(25-32)
Location H
Output
2-5
