Specifications, Part Numbers, Accessories, cont'd
Control/remote — switcher
Serial control port .......................... 1 bidirectional RS-232 or RS-422, female 9-pin D connector (rear panel)
Baud rate and protocol ................. 9600 to 115200 baud, 9600 baud (default), 8 data bits, 1 stop bit, no parity
Serial control pin configurations
Female 9-pin D connector RS-232: 2 = Tx, 3 = Rx, 5 = GND
Mini stereo jack .................. RS-232: tip = Tx, ring = Rx, sleeve = GND
Ethernet control port..................... 1 female RJ-45 connector
Ethernet data rate .......................... 10/100Base-T, half/full duplex with autodetect
Ethernet protocol ........................... ARP, ICMP (ping), IP, TCP, UDP, DHCP, HTTP, SMTP, Telnet
Default settings .............................. Link speed and duplex level = autodetected
Web server ...................................... Up to 200 simultaneous sessions
Program control ............................. Extron control/configuration program for Windows
General
Power* ............................................. 2 (positive-negative), 100 VAC to 240 VAC, 50-60 Hz; internal, hot-swappable
3200 Series .......................... 175 watts each (primary and redundant)
7200 Series .......................... 175 watts each (primary and redundant)
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling ........................................... Fan, right to left (as viewed from front panel)
Mounting
Rack mount ........................ Yes
Enclosure type ............................... Metal
Enclosure dimensions
B-4 FOX 4G Matrix Switchers • Specifications, Part Numbers, Accessories
1 bidirectional RS-232, 2.5 mm mini stereo jack (front panel )
RS-422: 2 = Tx-, 3 = Rx-, 5 = GND, 7 = Rx+, 8 = Tx+
IP address = 192.168.254.254
Subnet mask = 255.255.0.0
Gateway = 0.0.0.0
DHCP = off
7 MB nonvolatile user memory
Extron Simple Instruction Set (SIS
Microsoft Internet Explorer
®
A redundant power supply is standard.
*
Enclosure without boards: 31 watts at 115 VAC, 60 Hz
Enclosure fully loaded with 4 singlemode boards: 55 watts at 115 VAC, 60 Hz
Enclosure fully loaded with 4 multimode boards: 51 watts at 115 VAC, 60 Hz
Enclosure fully loaded with 4 SDI/HD-SDI boards: 67 watts at 115 VAC, 60 Hz
Each singlemode board: 6 watts at 115 VAC, 60 Hz
Each multimode board: 5 watts at 115 VAC, 60 Hz
Each SDI/HD-SDI board: 9 watts at 115 VAC, 60 Hz
Enclosure without boards: 34 watts at 115 VAC, 60 Hz
Enclosure fully loaded with 9 singlemode boards: 88 watts at 115 VAC, 60 Hz
Enclosure fully loaded with 9 multimode boards: 79 watts at 115 VAC, 60 Hz
Enclosure fully loaded with 9 SDI/HD-SDI boards: 119 watts at 115 VAC, 60 Hz
Each singlemode board: 6 watts at 115 VAC, 60 Hz
Each multimode board: 5 watts at 115 VAC, 60 Hz
Each SDI/HD-SDI board: 9.5 watts at 115 VAC, 60 Hz
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
®
)
™
ver. 6 or higher, Telnet
®
