Specifications, Part Numbers, Accessories, cont'd
Part Numbers and Accessories
FOX 4G matrix switcher part numbers
The matrix switcher is custom-built to your requirements. You need to specify the
the number, type, and transmission mode (for fiber optic boards) of I/O boards
desired when you order a unit. The following part numbers apply:
Matrix switcher part numbers
FOX 4G Matrix 3200 Switcher enclosure
FOX 4G Matrix 7200 Switcher enclosure
Singlemode fiber optic 8x8 I/O board
Multimode fiber optic 8x8 I/O board
FOX 4G I/O 88 SDI/HD-SDI board
Blank panel
Power supply module
Fan module
IEC power cords (2)
Rubber feet
FOX 4G Matrix Switcher Setup Guide
Extron Software Products disk
(Matrix Switchers Control Program and
Button Label Generator)
Replacement/configuration change parts
The following parts can be ordered to change the size of the matrix or to replace
components:
Part
Singlemode fiber optic 8x8 I/O board
Multimode fiber optic 8x8 I/O board
FOX 4G I/O 88 SDI/HD-SDI board
Blank panel, 1 I/O board space
Power supply module
Fan module
Button cap and diffuser kit (set of 3 button cap assemblies)
B-6 FOX 4G Matrix Switchers • Specifications, Part Numbers, Accessories
FOX 4G Matrix 3200 Switcher (2)
FOX 4G Matrix 7200 Switcher (2)
FOX 4G Matrix 3200 Switcher (1)
FOX 4G Matrix 7200 Switcher (2)
FOX 4G Matrix 3200 power supply module
FOX 4G Matrix 7200 power supply module
FOX 4G Matrix 3200 fan module
FOX 4G Matrix 7200 fan module)
Part number
60-878-01
60-1011-01
70-791-02
70-791-01
70-792-01
70-651-21
70-710-01
70-704-01
70-709-01
70-814-01
Part number
70-791-02
70-791-01
70-792-01
70-651-21
70-710-01
70-704-01
70-709-01
70-814-01
70-352-01
