PVS 407D • Setup Guide
The Extron PVS 407D is a seven input, one HDMI
output switcher with a built-in audio amplifier and
a 4-port Ethernet switch. The PVS 407D is part of
the PoleVault ® , PlenumVault
Digital Systems, and is used in conjunction with
the Extron PVT digital series of transmitters and Extron speakers. The PVS 407D accepts HDMI and high resolution (RGB)
video and audio signals. The RGB input is digitized at the PVT input wallplate. In addition, the switcher has dedicated ports for
connecting the optional VoiceLift
NOTE: For full installation, configuration, connector wiring, and operation details, see the PVS 407D User Guide, available at
www.extron.com

Installing and Cabling the PVS 407D Switcher

The PVS 407D may come already pre-mounted within the Extron PMK 560 Projector Mount Kit and the PVM 220 PlenumVault
Mount Kit.
However, if the switcher is not pre-mounted, follow the steps in the system installation guide, supplied with the complete
PoleVault, PlenumVault, or WallVault System. Alternatively, follow the steps in the relevant setup guide for the mounting kit
(PMK 560, PVM 220, WMK 160, or USFM 100). Connect the cables to the switcher as shown in
ATTENTION:
• The PoleVault signal transmission method is specific for PVS 405D switchers working with PVT digital wallplates. DO
NOT connect the input ports to an MTP system or to an Ethernet/LAN or data transmission system.
• La méthode de transmission du signal PoleVault est spécifique pour les sélecteurs PVS 405D qui fonctionnent avec les
plaques murales PVT numériques. Ne PAS connecter les ports d'entrée à un système MTP ou à un système Ethernet/
LAN ou de transmission de données.
NOTES:
• The PVS 407D can receive signals from PVT wallplates located up to 150 feet (45 meters) away.
• RJ-45 termination must comply with the TIA/EIA T 568A or 568B wiring standards for all connectors. The same standard
MUST be used at both ends of all cables (see the PoleVault System Installation Manual for details). The cables supplied
with the Extron PoleVault system are terminated to the TIA 568B standard.
• Extron XTP DTP 24 twisted pair cable is required for optimal performance.
1/2
SIG LINK
POWER
12V
3A MAX
PVT IN
M
Power Connector
PVT HD RGB
HDMI or RGB video/audio,
Supplied PVS Inputs 1/2 and 3/4,
Switcher External 1 XTP DTP 24 cable with RJ-45 connectors
Power Supply
(12 VDC, 4 A, or
12 VDC, 4.2 A)
Figure 1. PVS 407D Switcher Connections
