4. Confirm the change: Press and release the Enter button.
Press the Enter button to
confirm the configuration
change.
All input buttons and output buttons
ENTER
return to unlit or background illumination.
The Enter button returns to
unlit or background
illumination.
The current configuration is now input 5 tied to output 1, output 3, and
output 8.
Input 5 video tied
to outputs 1, 3, and 8
Input
5
1
3
Output
8
FOX 4G Matrix Switchers • Operation 3-15
