Proline Prosonic Flow W 400 HART
Endress+Hauser
Diagnostic Short text
number
Diagnostic of process
803 Loop current 1 faulty
832 Electronics temperature
too high
833 Electronics temperature
too low
841 Flow velocity too high
842 Process value below limit Low flow cut off active!
870 Measuring inaccuracy
increased
881 Signal to noise ratio too
low
882 Input signal faulty
930 Sound velocity too high
931 Sound velocity too low
953 Asymmetry noise signal
too high path 1 to n
1) Diagnostic behavior can be changed.
12.8

Pending diagnostic events

The Diagnostics menu allows the user to view the current diagnostic event and the
previous diagnostic event separately.
To call up the measures to rectify a diagnostic event:
• Via local display →  134
• Via web browser →  135
• Via "FieldCare" operating tool →  137
• Via "DeviceCare" operating tool →  137
Other pending diagnostic events can be displayed in the Diagnostic list submenu
→  142.
Remedy instructions
1. Check wiring
2. Change I/O module
Reduce ambient temperature
Increase ambient temperature
Reduce flow rate
Check low flow cut off configuration
1. Check process
2. Increase flow volume
1. Check process conditions
2. Clean/repl. transd. (inline) / check
sensor pos. and coupling (clamp on)
3. Replace sensor electronic module
(ISEM)
1. Check input signal
parameterization
2. Check external device
3. Check process conditions
1. Check process conditions
2. Clean/repl. transd. (inline) / check
sensor pos. and coupling (clamp on)
3. Replace sensor electronic module
(ISEM)
1. Check process conditions
2. Clean/repl. transd. (inline) / check
sensor pos. and coupling (clamp on)
3. Replace sensor electronic module
(ISEM)
1. Check process conditions
2. Clean or replace transducers
3. Replace sensor electronic module
(ISEM)
Diagnosis and troubleshooting
Status Diagnostic
signal behavior
[from the [from the
factory] factory]
F Alarm
S Warning
S Warning
S Warning
S Warning
1)
F Alarm
F Alarm
F Alarm
S Warning
S Warning
M Alarm
1)
1)
1)
1)
1)
1)
141
