Analog Devices ADV7610 Hardware User's Manual page 60

UG-438
Table 14. Selectable Mute Conditions
Bit Name
MT_MSK_COMPRS_AUD
MT_MSK_AUD_MODE_CHNG
MT_MSK_PARITY_ERR
MT_MSK_VCLK_CHNG
MT_MSK_APLL_UNLOCK
MT_MSK_VPLL_UNLOCK
MT_MSK_ACR_NOT_DET
MT_MSK_FLATLINE_DET
MT_MSK_FIFO_UNDERFLOW
MT_MSK_FIFO_OVERFLOW
MT_MSK_AVMUTE
MT_MSK_NOT_HDMIMODE
MT_MSK_NEW_CTS
MT_MSK_NEW_N
MT_MSK_CHMODE_CHNG
MT_MSK_APCKT_ECC_ERR
MT_MSK_CHNG_PORT
MT_MSK_VCLK_DET
HDMI Map
Address Description
0x14[5] Causes audio mute if audio is compressed
0x14[4] Causes audio mute if audio mode changes between
PCM, DSD, DST, or HBR formats
0x14[1] Causes audio mute if parity bits in audio samples are
not correct
0x14[0] Causes audio mute if TMDS clock has irregular/missing
pulses
0x15[7] Causes audio mute if audio PLL unlocks
0x15[6] Causes audio mute if TMDS PLL unlocks
0x15[5] Causes audio mute if ACR packets are not received
within one VSync
0x15[3] Causes audio mute if flatline bit in audio packets is set
0x15[1] Causes audio mute if audio FIFO underflows
0x15[0] Causes audio mute if audio FIFO overflows
0x16[7] Causes audio mute if AVMute is set in the general
control packet
0x16[6] Causes audio mute if HDMI_MODE bit goes low
0x16[5] Causes audio mute if CTS changes by more than the
threshold set in
0x16[4] Causes audio mute if N changes
0x16[3] Causes audio mute if the channel mode changes from
stereo to multichannel, or vice versa
0x16[2] Causes audio mute if uncorrectable error is detected in
the audio packets by the ECC block
0x16[1] Causes audio mute if HDMI port is changed
0x16[0] Causes audio mute if TMDS clock is not detected
Rev. 0 | Page 60 of 184
CTS_CHANGE_THRESHOLD[5:0]
Hardware User Guide
Corresponding Status
Register(s)
CS_DATA[1]
AUDIO_SAMPLE_PCKT_DET
PARITY_ERROR_RAW
VCLK_CHNG_RAW
AUDIO_PLL_LOCKED
TMDS_PLL_LOCKED
AUDIO_C_PCKT_RAW
AUDIO_FLT_LINE_RAW
FIFO_UNDERFLO_RAW
FIFO_OVERFLO_RAW
AV_MUTE_RAW
HDMI_MODE
CTS_PASS_THRSH_RAW
CHANGE_N_RAW
AUDIO_MODE_CHNG_RAW
AUDIO_PCKT_ERR_RAW
HDMI_PORT_SELECT[2:0]
TMDS_CLK_A_RAW
