Analog Devices ADV7610 Hardware User's Manual page 181

Hardware User Guide
Ball No.
A7
B6
A6
A5
B4
B5
A3
B3
A2
Mnemonic Type
INT1 Miscellaneous digital
RESET Miscellaneous digital
XTALP Miscellaneous analog
XTALN Miscellaneous analog
CEC Digital input/output
CS Miscellaneous digital
DDCA_SCL HDMI input
DDCA_SDA HDMI input
RXA_5V HDMI input
Description
Float this pin.
This level of this pin must be controlled by an external processor.
This pin is always connected to 28.63636 MHz crystal.
This pin is always connected to 28.63636 MHz crystal.
Float this pin.
Float this pin.
Connect this pin to ground via a 10 kΩ resistor.
Float this pin.
If RXA_5V is not used, float RXA_5V and set DIS_CABLE_DET_RST to 0.
In the case where Port A is not used, RXA_5V can be left unconnected.
Rev. 0 | Page 181 of 184
UG-438
